Name: 1760 Aluminum Jon Boat Plans with side console
SKU: 3702
Availability: InStock

1760 Aluminum Jon Boat Plans with side console

315,00 €

Hull length: 17′ (5,18m)
Hull width 80″ (2,03m)
Chine Width 60″ (1,52m)
Max MPH 30-32 mph
Side Depth 29,5″ (75 cm)
Cockpit Depth 23″ (58 cm)
Fuel Capacity – Portable
Deadrise 4,75°
Dry hul weight: 870 lbs (395 kg)
Weight (Boat + max engine, dry) 1135 lbs (515 kg)
Front Livewell Capacity: 20 Gal – 90 liters
Front Livewell Length: 32″ (82 cm) Long
Draft max. water line: 5″ – 7″ (12 – 19 cm)
Displacement max: 1796 lbs (815 kg)
Max Person weight 661 lbs (300 kg)
Maximum Persons 4
Design category „C”
Transom inclination angle 12 degrees
Transom Height: 20″ – 508mm (foot “L”)
Outboard engine: 20 HP – 60 HP

Description

For Pricing select Study Plans, CNC Cutting Files / Plans under, 1:1 PDF Plans and Offset Table Plans PDF the “Choose an Option” drop-down menu above.

Medium difficulty in building an aluminum jon boat.

Full cutting files plans available in metric versions and imperial version This welded aluminum skiff will take a beating and last a lifetime., safe and very stable on water.

This one provides a safe dry ride and load carrying for the real world.

Built with:

5/32″ bottom and sides, (4mm in metric version)

3/16″ frames and longituidals (5mm in metric version)

1/8″ seats, console and floor (3mm in metric version)

The full plans also include several additions that will allow you to build an even nicer and more practical boat.

The instructions also describe the welding process so that the aluminum does not bend.

Before purchasing “Study Plans”, read what study plans contain: What do study plans included?

Before purchasing “CNC cutting files / plans”, read what cnc files / plans contain: What do CNC cutting files / plans included?

Before purchasing “ 1:1 PDF Plans ”, read what cnc files / plans contain: What do 1:1 PDF Plans included?

Before purchasing “Offset Table Plans PDF”, read what cnc files / plans contain: What do Offset Table Plans PDF included?

Additional information

Chose Plans	CNC Files / Plans – Metric, CNC Files / Plans – Imperial, 1:1 PDF Plans – Metric, 1:1 PDF Plans – Imperial, Plotting Points PDF Plans – Metric, Plotting Points PDF Plans – Imperial, Study Plans – Metric, Study Plans – Imperial
